從時間敏感網絡的影響來看，兩個關鍵點很明顯。首先，行業應該考慮有哪些開放網絡技術可以幫助他們將當前的工業以太網系統遷移到與 TSN 兼容。其次，任何評估都需要結合 TSN 和千兆以太網。
智能工廠概念的實施旨在提供不斷提高的效率和生產力。通過提供在整個企業內外流動的連續數據流，可以實時監控和管理制造過程。時間敏感網絡 (TSN) 技術通過為當今的工業通信提供越來越全面的方法，使智能制造的前景更加接近。
連接性是當前工業領域正在經歷的數字化轉型的關鍵要求，其作用將繼續變得越來越突出。標準工業以太網長期以來一直很好地服務于制造業，多年來不斷發展，以應對工業通信中的新挑戰和要求。然而，它的一些功能正變得越來越過時，阻礙了企業采用工業 4.0。
只有圍繞智能制造、工業物聯網 (IIoT) 和大數據的需求構建的新技術才能成功解決這個問題。由 IEEE 802.1 定義的 TSN 為當前的工業以太網提供了通向未來的遷移路徑。
從根本上說，創建響應迅速且透明的網絡物理企業需要系統來監控、控制所有流程操作并做出分散的自主決策。實現這一目標的優雅方法是使用一個單一的工業網絡來提供信息技術 (IT) 和運營技術 (OT) 的必要融合。在實踐中，只有少數公司擁有這種。通常，任何給定的工廠都會有許多不同類型的網絡，因?yàn)殡S著時間的推移并根據不同的需求進行安裝。TSN 可以通過在同一網絡基礎設施上統一多個不同的工業以太網協議來解決這個問題。
這些功能由定義 TSN 的一組 IEEE 802.1 標準啟用。其中的關鍵是 802.1AS 和 Qbv。它們分別定義了網絡上設備的同步和控制流量的優先級。TSN 確保以可靠和確定的方式處理重要的過程數據，同時允許較低優先級的流量在同一網絡上共存。因此，TSN 不僅提供生產力優勢，而且還降低了與網絡基礎設施相關的擁有成本。
消除關鍵和非關鍵數據共享之間的任何物理隔離，簡化了網絡規劃，并降低了與布線和網絡管理相關的資本支出 (CAPEX) 和運營費用 (OPEX)。
注意力集中在 TSN 允許“標準”以太網具有確定性這一事實上。雖然這是真的，但 TSN 僅針對以太網的數據鏈路層。它不考慮工業以太網協議解決的更別的功能，例如安全和運動控制。尋找未來通信遷移路徑的用戶需要考慮如何將 TSN 與這些需求相結合，以確保高性能和功能。
此外，作為設備制造商目前可以選擇和混合的一系列開放 IEEE 技術標準，TSN 確保遵循相同 IEEE 802.1 子標準的技術之間的開放性和未來互連性。IEC/IEEE 60802 工作組目前正在以此為基礎，創建一組用于在自動化中使用 TSN 的配置文件，以確保標準化。
這些機會有可能有助于改進制造流程并提高采用 TSN 的企業的競爭力。從長遠來看，它們將改變?nèi)蛑圃鞓I(yè)。工廠自動化業務的主要參與者已經推出了一系列支持 TSN 的產品，因此這個概念不是理論上的未來世界，而是工業網絡發展中非常堅實的一步。TSN 提供的連接水平將有助于將生產工廠內的不同“自動化島”連接成一個獨立且自我協調的“生命系統”，以響應包括波動輸入和預定事件在內的許多變量。
TSN 可以支持的網絡物理系統不僅限于自動化，還可以擴展到資產管理和預測性維護。當與 OPC UA 結合使用時，TSN 提供了一個高效可靠的網絡，用于傳輸有關物理機器及其虛擬對應物性能的高質量真實數據。因此，可以創建高度準確且響應迅速的實時數字雙胞胎。
我司產品廣泛應用于數控機械 冶金,石油天然氣,石油化工，
化工,造紙印刷,紡織印染,機械,電子制造,汽車制造,
塑膠機械,電力,水利,水處理/環保,市政工程,鍋爐供暖,能源,輸配電。
These capabilities are enabled by the set of IEEE 802.1 standards that define TSN. Key amongst them are 802.1AS and Qbv. These define the synchronisation of devices on a network and control the prioritisation of traffic respectively. TSN ensures that vital process data is handled in a reliable and deterministic manner, while allowing lower priority traffic to co-exist on the same network. Hence, not only does TSN offer productivity benefits, but it also lowers cost of ownership associated with the network infrastructure.
The removal of any physical separation between critical and non-critical data sharing, simplifies network planning as well as reducing capital expenditure (CAPEX) and operating expenses (OPEX) associated with cabling and network administration.
Attention has been focused on the fact that TSN allows “standard” Ethernet to be deterministic. While this is true, TSN only addresses the data link layer of Ethernet. It does not consider higher level functions addressed by industrial Ethernet protocols, such as safety and motion control. Users looking for a migration path to future communications need to consider how TSN can be combined with these needs to ensure high performance and functionality.
Moreover, as a series of open IEEE technical standards that device makers can currently pick and mix, TSN ensures openness and future interconnectivity among technologies adhering to the same IEEE 802.1 sub-standards. The IEC/IEEE 60802 working group is currently building on this by creating a set of profiles for using TSN in automation to ensure standardisation.
Revolutionising smart manufacturing
These opportunities have the potential to contribute to improving manufacturing processes and increased competitiveness for businesses that adopt TSN. In the long term, they will transform global manufacturing. Major players in the factory automation business have already introduced a range of products that support TSN, so the concept isn’t a theoretical tomorrow’s world, but very much a solid step in the evolution of industrial networking. The level of connectivity offered by TSN will help to connect different ‘islands of automation’ within a production plant into one independent and self-coordinated ‘living system’ responsive to many variables including both fluctuating inputs and scheduled events.
Cyber-physical systems that TSN can support are not confined to automation but can be extended to asset management and predictive maintenance. When combined with OPC UA, TSN provides an efficient and reliable network for the transfer of high-quality, real-world data on the performance of physical machines and their virtual counterparts. As a result, it is possible to create highly accurate and responsive real-time digital twins.
